PD590

PD590 adds screen and keyboard on the basis of PD588, has more functions, and the keyboard lock function helps users to prevent miscontact. Keyboard increase efficiency by sharing information via pre-programmed short messages. PD590 has professional IP67 dustproof and waterproof grade, superior protection performance ensures the radio stability of communication even in harsh climates or complex environments. PD590 has two functions optional: noise cancelling and voice recording. Noise cancelling, through the built-in professional noise reduction algorithm to filter noise, to achieve clear voice transmission; Voice recording function helps users record important conversations. Complete voice call functions, providing standard signaling call modes: individual call, group call, and all call. The voice encryption function protects users' calls.

● IP67 dustproof and waterproof grade
● Programmable Side Key
● Noise Cancelling(Optional)
● Voice Recording (Optional)
● Keypad Operations
● Short Messages
● Basic Encryption
● Digital Emergency System
● Lone Work
● Repeater
● Talk Around
● Private/Group/All Call
● Direct Mode (True 2-slot)
● Channel Free
● Squelch Tail Elimination
● TX Interrupt
● Squelch Tail Elimination

Model: PD590

Frequency Range: UHF400-470MHz

Number of Channels:1,000Channel/250Zones

Channel Spacing: Analog: 25/12.5 kHz  Digital: 12.5 kHz

Operating Voltage: 7.4V DC±20%

Frequency Stability: ±2.5PPm

Antenna Impedance: 50Ω

Standard / Vocoder: Dual Mode: Digital(DMR/AMBE++) & Analog

IP Rating: IP67

Battery Capacity: 1,800mAh/13.32Wh  1,600mAh/11.84Wh

Size: H x W x D: 115x57x38mm(Not Inc. Antenna)

Weight: 224g (Inc. Standard Li-ion Battery)
