Model: PD589
Frequency Range: UHF400-470MHz
Number of Channels:1,000Channel/250Zones
Channel Spacing: Analog: 25/12.5 kHz Digital: 12.5 kHz
Operating Voltage: 7.4V DC士20%
Frequency Stability: ±2.5PPm
Antenna Impedance: 50Ω
Standard / Vocoder: Dual Mode: Digital(DMR/AMBE++) & Analog
IP Rating: IP67
Battery Capacity: 1,800mAh/13.32Wh 1,600mAh/11.84Wh
Size: H x W x D: 115x57x38mm(Not Inc. Antenna)
Weight: 224g (Inc. Standard Li-ion Battery)
Receiver
Selectivity: Analog @ 25 / 12.5 kHz: 70dB/65dB
Sensitivity: Digital 1 % BER:0.7μV(or-110dBm) Digital 5 % BER:0.3μV(or-117.4dBm)
Analog(12dB SINAD): 0.25μV(or-120dBm)
Intermodulation Distortion: Analog: ≥65 dB
Audio Output: 1 W/16ohm (Internal speaker)
Audio Distortion: ≤5%
Spurious Response: Analog: ≥70 dB
Transmitter
FM Noise: Analog @ 25 kHz: 45dB/12.5 kHz: 40 dB
RF Power Output: Digital: High/Low:4W/1W
Spurious Response: ≤-36dB
Audio Distortion: ≤3%
Emission Designator: Analog mode: 16K0F3E,14K0F2D, 11K0F3E,7K50F2D
Digital mode: 7K60FXE,7K60FXD
