PD826

PD826 adds screen and keyboard on the basis of PD825, has more function. The appearance design with two-color and has two color design(black gray and gray red), colors can be customized according to customer needed. PD826 supports IP67 dustproof and waterproof, even in harsh climates complex environments, it can ensure the stability of communication. The unique screen allows user see the screen information clearly under direct sunlight. PD826 has analog and digital dual mode, up to 1,000 channels. Digital voice encryption function protects user's call. With optional voice recoeding function, PD826 can help user records important conversation information. The PD826 has a complete set of voice call functions, providing standard signaling call modes: individual call, group call, and all call. The 2,600mAh battery capacity provides the PD826 with ultra-long battery service.

● Programmable Side Key
● Voice Recording (Optional)
● Keypad Operations
● Basic Encryption
● Digital Emergency System
● Scan
● Lone Work
● Repeater
● Talk Around
● Private/Group/All Call
● Direct Mode (True 2-slot)
● Channel Free
● Squelch Tail Elimination

Model: PD826

Frequency Range: UHF400-470MHz

Number of Channels: 1,000Channel/250Zones

Channel Spacing: Analog: 25/12.5 kHz  Digital: 12.5 kHz

Operating Voltage: 7.4V DC20%

Frequency Stability: ±2.5PPm

Antenna Impedance: 50Ω

Standard / Vocoder: Dual Mode: Digital(DMR/AMBE++) & Analog

IP Rating: IP67

Battery Capacity: 2,600mAh/19.24Wh

Size: H x W x D: 262.23x62.15x43.76mm(Withstandard Li-ion battery and antenna)

Weight: 357g (With standard Li-ion battery and antenna )
