PX-V9

PX-V9

PX-V9 is a basic radio, small size, compact structuree, simple appearance and operation, PX-V9 has customized communication module and antenna, high-sensitivity receiving module and high-efficiency antenna to enhance signal penetration, compared to traditional antenna, PX-V9’s extends the radio communication distance; Build-in VOX, user needn’t to press PTT when using the earphone to call. The radio is equipped with voice annunciation, without visual radio, voice annunciation can annunciate the current channel.

● Talk Arounnd
● 50 CTCSS and 105 DCS
● 16 Store Channels
● Reverse Frequency Function
● Side Keys Programmable
● VOX Function
● Emergency Call
● Monir
● Busy Channel Lockout
● Scan
● DTMF ANI Encode
● Battery Save
● Scan Temperary Delete
● Squelch Level 0-9 Adjustable
● End Roger
● High/Low Power Selectable
● TOT 0-270s

Model: PX-V9

Frequency Range: 400~470MHZ

Operating Voltage: DC 7.4V

Work Mode: Simplex or Semi-duplex

Weight: About 190g (with Li-ion Battery)

Dimension: HxWxD: 114*59*34mm(exclude antenna)

Working Temperate: -25℃~+55℃

Antenna Impedance: 50Ω
