Model: PX-V6
Frequency Range: 400~470MHZ
Operating Voltage: DC 7.4V
Work Mode: Simplex or Semi-duplex
Weight: About 193g (With Li-ion Battery)
Dimension: HxWxD: 114*59*34mm(Exclude antenna)
Working Temperate: -20℃~+50℃
Antenna Impedance: 50Ω
Transmitter
Frequency Stability: ±2.5PPM
Output Power: 5W
Max Frequency Deviation: ≤5KHz/2.5KHz
Audio Distortion: ≤5%
Modulation Character: +3dB ~-3dB
Adjacent Channel Power: ≥65dB
Spurious Radiation: ≤7.5μW
Occupied Bandwidth: ≤16KHz
Receiver
RF Sensitivity: <0.2μV
Audio Distortion: ≤3%
Audio Response: +2dB ~-10dB
Same Channel Restrain: ≥-8dB
Adjacent Channel Selectivity: ≥60dB
Intermodulation Rejection: ≥85dB
Spurious Response: ≥70dB
Blocking: ≥80dB
